36-inches 6-Pin (2x3) 2.54mm-Pitch Female to Female IDC 6-Wire Flat Ribbon Cable
Product Details
36-inches 6-Pin (2x3) 2.54mm-Pitch Female to Female IDC 6-Wire Flat Ribbon Cable
These 6-Pin (2x3) Female to Female 2.54mm-Pitch 6-wire IDC Flat Ribbon Cable features one 6-pin (2x3) connector on one end and one 6-pin (2x3) connector on the other end.
Specifications:
- Connector A: IDC 6-Pin (2x3) 2.54mm-Pitch Female Connector
- Connector B: IDC 6-Pin (2x3) 2.54mm-Pitch Female Connector
- Sturdy nylon construction ribbon cable
- Current Rating (per Wire): 1A, Voltage Rating: 300V
- Operating Temperature Range: -20°C to +105°C
- Connector Pitch: 2.54mm
- Wire Pitch: 1.27mm
- Wire Gauge: 28AWG
- Wire Width: 0.3-inch (7.62mm)
- Length: 36 inches
CablesOnline Part Number: FR-0636
